TEXONIC A-2120H 120W 2-Zone Commercial Mixer Amplifier with Bluetooth & Paging

TEXONIC A-2120H 120W 2-Zone Commercial Mixer Amplifier with Bluetooth & Paging

A-2120H

$549.99 CAD
$549.99 CAD
Sale Sold out
Shipping calculated at checkout.
120W Commercial Music & Paging Amplifier

TEXONIC A-2120H 2-Zone Mixer Amplifier

Bring music and voice announcements together with the TEXONIC A-2120H, a 120W commercial mixer amplifier for businesses that need simple sound control across two speaker areas.

Play everyday background music through Bluetooth, USB or SD media, connect microphones for paging, and select which business areas receive sound using two front-panel zone switches.

Designed for 100V commercial speaker systems, the A-2120H is a practical solution for cafés, boutiques, reception areas, offices, clinics and smaller shared commercial spaces.

120W Rated Output 2 Selectable Zones 100V Commercial Audio Bluetooth + USB / SD MIC1 Priority Paging
Manual

Simple Music and Paging for Two Areas

The TEXONIC A-2120H brings background music and microphone announcements into a single 120W unit for smaller business audio installations.

It is designed for businesses that want straightforward audio operation without installing a separate amplifier for each area. Use Zone 1, Zone 2 or both together depending on which areas need music or announcements.

Its 120W output is suited to a properly planned 100V speaker installation. Choose speaker wattage taps based on the room, coverage needs and total amplifier loading.

Cafés & Small Restaurants Select music for a dining area or a separate counter and seating space.
Boutiques & Retail Serve the shop floor and staff room from one background music source.
Clinics & Offices Provide music in reception and selected shared areas, with microphone paging when needed.
Community & Work Spaces Add everyday music and announcements in two small listening areas.
Choosing the Right System: The A-2120H is a good fit for two modest speaker areas sharing one music and paging programme. Different music in each area requires a suitable independent multi-zone or matrix audio system.

Key Features

  • 120W rated commercial mixer amplifier
  • Two selectable front-panel speaker zones
  • 100V distributed speaker output
  • Separate 4–16Ω low-impedance output option
  • Bluetooth wireless music playback
  • USB and SD media playback
  • MP3 and WMA audio format support
  • Microphone connections for business paging
  • MIC1 voice priority background music ducking
  • MIC2 delay and echo adjustments
  • MIC3 and MIC4 selectable for microphone or AUX input use
  • Additional MIC5 and MIC6 connections
  • CD input for compatible external sources
  • Line output for compatible external audio equipment
  • REC output for compatible recording equipment
  • Individual input level adjustments
  • Front panel bass and treble controls
  • Master volume adjustment
  • Front panel LED audio level meter
  • Rack mount hardware included
Paging Tip: MIC1 includes a priority mute function that can lower background music during voice announcements.

Technical Specifications

Brand TEXONIC
Model A-2120H
Amplifier Type 2-Zone Commercial Mixer Amplifier
Rated Output 120W
Power Rating Condition 1kHz, THD+N = 1%
Speaker Zones 2 selectable zones
Zone Operation Zone 1 / Zone 2 / both
Commercial Speaker Output 100V
Low-Impedance Output 4–16Ω
Bluetooth Built-in Bluetooth audio playback
USB / SD USB and SD media playback
Audio Formats MP3 / WMA
Microphone Inputs MIC1–MIC6, with MIC3/4 sharing selectable AUX inputs
Additional Audio Inputs AUX1 / AUX2 / CD
Audio Outputs Line output / REC output
Microphone Priority MIC1 mute / ducking
MIC2 Controls Delay / Echo
Tone Controls Bass / Treble
Volume Controls Input levels / Master volume
Frequency Response 100Hz–15kHz (±3dB, 8Ω, 1W)
Signal-to-Noise Ratio Greater than 50dB
THD+N ≤1% at 1kHz, half power
Line Input Sensitivity ≤200mV
Microphone Input Sensitivity ≤15mV
Power Requirement AC 120V / 60Hz
Dimensions (W × H × D) 430 × 88 × 260mm
Dimensions (Inches) 16.93 × 3.46 × 10.24in
Net Weight 7.6kg / 16.75lb
Output Selection: Use either the commercial 100V two-zone speaker connection or the compatible 4–16Ω low-impedance connection. Do not operate both speaker output configurations simultaneously.

How the Two Speaker Zones Work

The A-2120H uses two front-panel switches to select which connected 100V speaker areas receive sound.

Zone 1 — Main Area Example: Restaurant dining room, showroom, retail floor or main office.
Zone 2 — Secondary Area Example: Reception, secondary seating, hallway, staff area or stockroom.

Three Operating Options

Zone 1 Only Send the shared music and paging programme to Zone 1.
Zone 2 Only Send the shared music and paging programme to Zone 2.
Both Zones Enable both areas so they receive the same programme.
Shared Amplifier Power Both speaker zones operate within the amplifier's combined 120W capacity.
Important: The two zones do not play different music sources independently. They also do not have separate built-in zone volume controls.
Need Local Volume Control? Compatible commercial speaker volume controls may be considered when an installation requires different listening levels in individual rooms. The complete speaker load and control ratings must be checked.

100V Speaker Compatibility & Loading

On a 100V commercial audio system, the connected speaker load is calculated by adding the selected transformer wattage taps of all connected speakers.

The A-2120H delivers 120W of rated amplifier output shared across its connected speaker system.

120W Rated amplifier output
96W Conservative planning load
24W 20% planning headroom

Example Speaker Loading

Speakers 100V Tap Total Load Capacity Remaining
4 10W 40W 80W
8 10W 80W 40W
12 5W 60W 60W
Recommended Planning Approach: Allow approximately 20% amplifier power headroom when designing the distributed speaker system. For the A-2120H, this gives a conservative planning target of about 96W in combined 100V speaker taps. This is a design recommendation, not a separate manufacturer power rating.

Can I Connect Regular 8Ω Speakers?

Yes. The amplifier also provides a separate 4–16Ω output for suitable low-impedance speaker systems. The combined speaker impedance must remain within the supported range.

Can I Connect Another Amplifier?

Yes. The line output can connect compatible external audio equipment, including an additional power amplifier. The manual also identifies an active subwoofer as a possible line-output connection.

Speaker Connection Notice: Do not use the 100V zone speaker outputs and the low-impedance speaker output at the same time. Turn off the amplifier before connecting speakers or changing wiring.
System Planning: Final speaker quantity, transformer tap settings and placement depend on room layout, ceiling height, ambient noise and the required listening level.

What's Included

1 × TEXONIC A-2120H 120W 2-Zone Commercial Mixer Amplifier
Rack Mount Hardware
AC Power Cable
User Manual
